Product Features
CAPACITY
The WC68 operates on tractors with 20 to 50 HP at the PTO. It has a large 23” x 27” (58 cm x 69 cm) infeed hopper opening that tapers down to a 6” x 8” (15 cm x 20 cm) opening where the 8.25” (21 cm) diameter roller grabs the branches and feeds them through the chipper. Branches as small as ¼” (6 mm) diameter and as large as 6” (15 cm) diameter can be fed through the WC68. To chip full 6” (15 cm) diameter logs at full infeed speed, a tractor with over 40 HP at the PTO is required.
HYDRAULIC INFEED SYSTEM
Branches are pulled into the WC46 with the 8.25” (21 cm) diameter infeed roller. The roller is hydraulically driven by the chipper's self-contained hydraulic system, and the hydraulic pump is belt driven from the main flywheel shaft. The infeed roller is adjustable in direction and speed, making it easy to feed branches of all shapes and sizes. The roller down pressure may be adjusted via two large springs, ensuring it grabs branches and easily pulls them in, eliminating the need for manual feeding.
FLYWHEEL
The dynamically balanced 24” (61 cm) diameter, 3/4” (2 cm) thick solid steel flywheel runs on a 2” (5 cm) diameter shaft, supported by 2 industrial and greaseable flanged bearings. It features four CNC-machined pockets to hold the reversible blades. The flywheel features four large fan blade paddles that spin at over 540 RPM.
FLYWHEEL LOCKING PIN
No more unsafe blade changes with the Woodland Mills flywheel locking pin. The WC68 features a flywheel locking pin that makes blade changes or flywheel maintenance convenient and safe. The pin simply fits into a series of holes that are positioned so every blade can be easily accessed while being changed or reversed.
REVERSIBLE CHIPPER BLADES
The WC68 chipper utilizes four high-quality hardened steel reversible chipper blades. These blades are 90 degrees apart, and can be reversed to take advantage of having two cutting edges on each blade. The blades are held onto the flywheel with four countersunk M10 bolts and locking nuts. Blades can be changed very quickly, thanks to the clamshell flywheel housing design. Simply undo one bolt and the upper flywheel housing rotates open, providing full access to the flywheel and chipper blades.
FOLDING INFEED CHUTE
The infeed chute on the WC68 wood chipper has a large 23” x 27” (58 cm x 69 cm) opening, making it easy to feed branches with multiple limbs effortlessly. The infeed chute can also be folded up to decrease the footprint of the chipper during transport or storage.
INFEED OPENING
The infeed chute on the WC68 wood chipper has a large 23” x 27” (58 cm x 69 cm) opening, making it easy to feed branches with multiple limbs effortlessly. The infeed chute can also be folded up to decrease the footprint of the chipper during transport or storage.
DISCHARGE CHUTE
The opening in the flywheel housing is 6” x 8” (15 cm x 20 cm), making it capable of accepting branches with several limbs. This reduces the need to trim branches down before feeding them into the chipper.
PTO SHAFT INCLUDED
The PTO shaft, complete with shear pin, is included with the WC68 chipper.
ASSEMBLY
The WC68 chipper arrives in a steel crate and can be up and running in as little as one hour. The infeed chute and discharge chute are removed during shipping to eliminate the possibility of damage. The chipper will require 5 gallons (20L) of ISO 32 hydraulic oil in the tank, which is not included, but can be purchased at most farm or hardware stores. Lastly, attach the PTO shaft that comes included and trim it to length for your tractor, as per the manual if required.
WEIGHT
The WC68 was designed for property owners, but is built like a commercial wood chipper. It weighs in at 710 lbs (320 kg).
Specifications
Manuals and Drawings
Shipping and Pick-up
Woodland Mills strives to make your shopping experience easy. We want to get your equipment to you as soon as possible. Once you place your order, you can trust that our customer service and delivery partners take care to ensure the best experience possible.
Shipping Weight: 825 lb (374 kg)
Remote locations and regions are excluded from flat rate shipping. If you are in a remote rural area, our sales staff will contact you to review additional shipping costs.
Warranty
At Woodland Mills, we put our customers first. If you have any questions about a product you purchased, you can contact us at 1-855-476-6455. The WC68 is backed by the 3-year Woodland Mills warranty (excludes wearing parts and cosmetic damage).
